HWR

The valve runs by pressure, used to control the cooling water flow rate. This valve can adjust the opening to make enough refrigeration flow by recept the change of pressure from the circulation of cooling water, it will save a lot of refrigeration water.

Product

Pressure Actuated Water Regulating Valve

Type

HWR (for fresh water) HMWR (for seawater)

Application

The valve runs by pressure, used to control the cooling water flow rate.

Material

Valve body: bronze (5-5-5 tin bronze)

Valve disk: 316 stainless steel, 304 stainless steel

Temperature range of liquid

-25℃~+130℃

Specification

1’NPT, 3/4’NPT, 1/2’NPT, 3/8’NPT

Range of pressure (opening)

6kgf/cm2 (85.6psi)~ 18kgf/cm2 (257psi)
